Product Details:
Payment & Shipping Terms:
|
| Machine: | Double Head Low-E Glass Edge Remover | Model: | SBT-BCM01 |
|---|---|---|---|
| Max. Glass Size: | 2200x1600mm | Min. Glass Size: | 200x540mm |
| Glass Thickness: | 3~20mm | Deleting Speed: | 20m/min |
| Control System: | PLC | ||
| High Light: | double glazing manufacturing equipment,double glass machine |
||
| Packaging Details: | Standard Export Package/Wooden Crate |
|---|---|
| Delivery Detail: | 10-30days |
Feature:
Semi-Automatic Horizontal Double Heads Low-E Glass Edge Deleting Machine is mainly used to remove coating on the coated glass around the insulating glass layer
to meet the requirements of doing,using the adjacent on both sides of the same time, inter membrane,
high production efficiency, in addition to film width, thickness adjustable, PLC control the whole
paragraph.Horizontal Double Head Low-E Glass Edge Deleting Machine,Semi-Automatic Horizontal Double Head LowE Glass Edge Deleting Machine.Glass aircraft identification after
the photoelectric switch automatically starts grinding wheel,according to glass size automatically
shut down, equipped with aircushion,vacuum system,to start with the wheel at the same time stop,
in order to achieve the purpose of saving electricity.
Technical Parameter:
1. Power Supply:380V 3P 50HZ
2. Total Power:4.1KW
3. Deleting Speed:20m/min
4. Max Glass Size:2200×1600mm
5. Glass Thickness:3—20mm
6. Overall:3100×2400×1200mm
7. Weight:500Kg
8.Suits for 200*76.2*10/12/15/20/25/30mm Grinding Wheels
Technical Parameter:
|
Max. Glass Size |
2200*1600mm |
|
Glass Thickness |
3~20mm |
|
Glass Deleting Speed |
20m/min |
|
Power |
4.1Kw |
|
Weight |
500kgs |
|
Overall Dimensions |
3100×2400×1200mm |
SAINT BEST GROUP selected each part carefully , we are strive to quality first when machine production and test each machine before delivery. So we will provide the best machine for you.Horizontal Low-E Glass Edge Deleting Machine,Double Head Low-E Glass Edge Deleting Machine.
SAINT BEST GROUP engineers have years of experience in window machine fabrication, which makes the precision and stability better than others.
After machine production finished, the products will be tested in professional ways make sure its performance.Horizontal Dual Head Low-E Glass Edge Deleting Machine,Dual Head Low-E Glass Edge
Deleting Machine.
SAINT BEST GROUP produce high quality machines, also pay attention to package.
The machines will be packed with steel pallet and standard export wooden case,
to make sure customer will receive the machines they ordered Intact.Horizontal Two Head Low-E Glass Edge Deleting Machine,Two Head Low-E Glass Edge Deleting
Machine.
Before Sale:
Free professional design for each customer especially.
After sale service :
24 hours technical support by phone, email or skype (email or skype) .
1years warranty period
Our senior engineer is available to travel aboard, help the installation, maintenance and training staff.
By offering this support, we make sure the cutomer start the business smoothly, to realise win-win cooperation.
Payment Terms :
♦ T/T, 30% deposit by T/T,70% spare payment before shipment.
♦ Western Union or Paypal
A,12month warranty
B,1%-2% spare parts
C, OEM&ODM are welcomed
D,Trail orders are available
Our senior engineer is available to travel aboard, help the installation, maintenance and training staff.
By offering this support, we make sure the cutomer start the business smoothly, to realise win-win cooperation.Horizontal Double Head Low-E Glass Edge Remover,Semi-Automatic Horizontal Double Head Low-E Glass Edge Remover, Horizontal Low-E Glass Edge Remover.
Saint Best Group always looking for long term cooperaion, not one time deal.Double Head Low-E Glass Edge Remover, Horizontal Dual Head Low-E Glass Edge Remover.
Our Advantage:
Our company owns excellent team of research and development and technician which lay foundation of high-quality machine. We use are imported components and after machine production finished, the products will be tested in professional ways make sure its performance.Dual Head Low-E Glass Edge Remover, Horizontal Two Head Low-E Glass Edge Remover,
Two Head Low-E Glass Edge Remover.
1. Question:Are you manufacture?
Answer:
Yes,we are the professional manufacture which have more than 5 workshops.
2.Question: About this Machine,What’s the guarantee ?
Answer:
1).Our guarantee for 12 months.
2).24 hour’s technical support by email or calling
3).English manual and video tutorial
4).We will provide the consumable parts at an agency price
5).24 hours on line service each day, free technical support.
3.Question:Why your price is higher than another company or factories ?
Answer: please check, what is is the differences of the machine of parts ,service and guarantee,especially the machine inner electric parts.Horizontal Double Head Low-E Glass Edge Deleting Machine,Semi-Automatic Horizontal Double Head Low-E Glass Edge Deleting Machine, Horizontal Low-E Glass Edge
Deleting Machine,Double Head Low-E Glass Edge Deleting Machine.
