8mm All Black: | Warm Edge Duraseal Spacer | Color: | Black&Grey |
---|---|---|---|
Usage: | Insulating Glass Sealing | Application: | Double & Triple Glazing |
High Light: | warm edge spacer bar,insulated glass spacer |
Insulating Glass Flexible Aluminium Spacer Bars For Double / Triple Glazing
Warm Edge Spacer for Insulating Glass/ Double Glazing
Our complex butyl glass gasket is a newly developed product by ourselves,which over comes the
disadvantages of the old type gasket. The new kind of gasket can be used together with other types of
sealing rubber such as silicone,and it can meet the demands of the hollow glass in the stage wall.
The product fills the blank of the domestic industry and it is in the leading position of the field.
Our stage wall complex butyl gasket is made of 5 kinds of good quality materials and 6 layers in total
1 Wavy aluminum belt is flexible and acts as stable supporting unit,which is easily curled.
2 High molecular traction belt high strength rigid structure resisting the
3 heat insulation material is a continuous water gas screen containing metal, which is heat insulated.
4 Modified sealing rubber has good adhesive and bonding properties with glass, and the water and gas
insulation effect is high,which has excellent properties of insulation of water, gas and argon.
5 The grey and black desiccant layer, which make the quick reaching dewing point of the hollow glass
decrease.Truseal Spacer,Duraseal Spacer,Duralite Spacer,Swiggle Spacer,Truspacer,SuperSpacer,Truseal Warm Edge Spacer,Duraseal Warm Edge Spacer,Duralite Warm Edge Spacer,Swiggle Warm Edge Spacer,Warm Edge Truspacer,Super Warm Edge Spacer,Truseal,Duraseal,Duralite,Super Spacer,Warm Edge Spacer,Butyl Tape,Butyl Spacer,Butyl Sealing Strip.
Warm Edge Spacer Technical Data | ||||||||
Size | code | Follow The Picture | Press Min | Press Max | Roll/M | Kg/Carton | ||
A | B | C | ||||||
-0.08 | -0.38 | -0.38 | ||||||
0.08 | 0.75 | 0.38 | ||||||
6 | 25H | 5.5 | 7.7 | 6.4 | 6.15 | 6.6 | 805 | 46-52 |
8 | 31H | 6.5 | 9.5 | 6.4 | 7.7 | 8.2 | 762 | 60-65 |
9 | 35H | 8 | 11.2 | 6.4 | 9.32 | 9.78 | 683 | 59-64 |
10 | 39H | 8.5 | 11.8 | 6.4 | 9.85 | 10.31 | 671 | 64 |
11 | 43H | 9.5 | 12.6 | 6.4 | 10.91 | 11.37 | 619 | 58 |
12 | 48H | 10.8 | 14 | 6.8 | 11.96 | 12.42 | 533 | 50-55 |
12.7 | 50H | 11.2 | 14.5 | 6.8 | 12.5 | 12.95 | 533 | 56 |
14.5 | 56H | 12.8 | 15.8 | 6.8 | 14.08 | 14.54 | 497 | 49 |
16 | 62H | 14.5 | 17.5 | 6.8 | 15.67 | 16.13 | 463 | 43-50 |
19 | 75H | 17.5 | 20.6 | 6.8 | 18.85 | 19.3 | 399 | 45 |
Specifications
warm edge spacer
1.A new energy-saving product,
2.Mainly used in insulating glass,
3.Highly cost effectiveness produc
Warm Edge Spacer
By advanced production technology and strict management system, our quality is comparable with any like product.
1.The unique formula makes the properties of the sealing spacer not change according to temperature and humidity.
2.The framework of the new and multi-aluminum sealing spacer is composed of aluminum strip,
plastic heat insulation strip and aluminum foil, the tensile strength is greatly improved.
3.Highly cost effectiveness products.
4.Use one product to do the whole job of several components,such as aluminium spacer bar,molecular sieve and so on.
Place of Origin: | China |
---|---|
Brand Name: | Saint Best |
Certification: | ISO etc |
Model Number: | SBT-WES-6-19mm |
Minimum Order Quantity: | 1 Cartons |
---|---|
Price: | Negotiable |
Packaging Details: | Carton or Customized |
Delivery Time: | 15-30days |
Payment Terms: | T/T,Western Union,Paypal,Mongram |
Supply Ability: | 60000000m/Month |
