Black Butyl Sealing Spacer , Insulated Glass Spacer Bars For Double Glazed Units

Good quality Insulating Glass Production Line for sales
Good quality Insulating Glass Production Line for sales
Very pleasure to cooperate with Saint Best, I am deeply pressed at their professional and quick response.

—— Davis Lyn

Very good quality and very competitive price.Also their professional and good pre-sale and after sales services.

—— Ahmed Rajesh

We are new in this feild.Thanks for Saint Best’s patient introduce, professional advice and prompt reply. They helped me a lot.

—— William Richard

Good quality and reasonable price. Wish your company business better and better.

—— Sebastian Carlos

When you choose your partners, you increase the likelihood of success. That’s why we choose Saint Best. Thanks!

—— Frank Neil

Good Quanlity. Reasonable Price. Fast Delivery. Good Package. Perfect Services.

—— Perez Luis

I'm Online Chat Now

Black Butyl Sealing Spacer , Insulated Glass Spacer Bars For Double Glazed Units

China Black Butyl Sealing Spacer , Insulated Glass Spacer Bars For Double Glazed Units supplier
Black Butyl Sealing Spacer , Insulated Glass Spacer Bars For Double Glazed Units supplier Black Butyl Sealing Spacer , Insulated Glass Spacer Bars For Double Glazed Units supplier Black Butyl Sealing Spacer , Insulated Glass Spacer Bars For Double Glazed Units supplier Black Butyl Sealing Spacer , Insulated Glass Spacer Bars For Double Glazed Units supplier Black Butyl Sealing Spacer , Insulated Glass Spacer Bars For Double Glazed Units supplier

Large Image :  Black Butyl Sealing Spacer , Insulated Glass Spacer Bars For Double Glazed Units

Product Details:

Place of Origin: China
Brand Name: Saint Best
Certification: Valid
Model Number: SBT-WES6~19MM

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Carton or customized
Delivery Time: 10~15days
Payment Terms: T/T
Supply Ability: 1000Cartons/Month
Contact Now
Detailed Product Description
Warm Edge Spacer: 6mm Black Color: 9mm Black&Grey
Warm Edge Duraseal Spacer: 12mm All Balck Package: Carton
High Light:

warm edge spacer bar

,

insulated glass spacer

    Warm Edge Spacer for Insulating Glass/ Double Glazing

Our complex butyl glass gasket is a newly developed product by ourselves,which over comes the

disadvantages of the old type gasket. The new kind of gasket can be used together with other types of

sealing rubber such as silicone,and it can meet the demands of the hollow glass in the stage wall.

The product fills the blank of the domestic industry and it is in the leading position of the field.

Our stage wall complex butyl gasket is made of 5 kinds of good quality materials and 6 layers in total
1 Wavy aluminum belt is flexible and acts as stable supporting unit,which is easily curled.
2 High molecular traction belt high strength rigid structure resisting the
3 heat insulation material is a continuous water gas screen containing metal, which is heat insulated.
4 Modified sealing rubber has good adhesive and bonding properties with glass, and the water and gas

 insulation effect is high,which has excellent properties of  insulation of water, gas and argon.
5 The grey and black desiccant layer, which make the quick reaching dewing point of the hollow glass

decrease.Truseal Spacer,Duraseal Spacer,Duralite Spacer,Swiggle Spacer,Truspacer,SuperSpacer,Truseal Warm Edge Spacer,Duraseal Warm Edge Spacer,Duralite Warm Edge Spacer,Swiggle Warm Edge Spacer,Warm Edge Truspacer,Super Warm Edge Spacer,Truseal,Duraseal,Duralite,Super Spacer,Warm Edge Spacer,Butyl Tape,Butyl Spacer,Butyl Sealing Strip.

Warm Edge Spacer Technical Data
Size code Follow The Picture Press Min Press Max Roll/M Kg/Carton
A B C
-0.08 -0.38 -0.38
0.08 0.75 0.38
6 25H 5.5 7.7 6.4 6.15 6.6 805 46-52
8 31H 6.5 9.5 6.4 7.7 8.2 762 60-65
9 35H 8 11.2 6.4 9.32 9.78 683 59-64
10 39H 8.5 11.8 6.4 9.85 10.31 671 64
11 43H 9.5 12.6 6.4 10.91 11.37 619 58
12 48H 10.8 14 6.8 11.96 12.42 533 50-55
12.7 50H 11.2 14.5 6.8 12.5 12.95 533 56
14.5 56H 12.8 15.8 6.8 14.08 14.54 497 49
16 62H 14.5 17.5 6.8 15.67 16.13 463 43-50
19 75H 17.5 20.6 6.8 18.85 19.3 399 45

Specifications

 warm edge spacer
1. A new energy-saving product,
2. Mainly used in insulating glass,
3. Highly cost effectiveness produc



      Warm Edge Spacer
By advanced production technology and strict management system, our quality is comparable with any like product.


1. The unique formula makes the properties of the sealing spacer not change according to temperature and humidity.

2. The framework of the new and multi-aluminum sealing spacer is composed of aluminum strip,

plastic heat insulation strip and aluminum foil, the tensile strength is greatly improved.

3. Highly cost effectiveness products.

4. Use one product to do the whole job of several components,such as aluminium spacer bar,molecular sieve and so on.

Product Details:
Place of Origin: China
Brand Name: Saint Best
Certification: ISO etc
Model Number: SBT-WES-6-19mm





Payment & Shipping Terms:
Minimum Order Quantity: 1 Cartons
Price: Negotiable
Packaging Details: Carton or Customized
Delivery Time: 15-30days
Payment Terms: T/T,Western Union,Paypal,Mongram
Supply Ability: 60000000m/Month





















Usage and attention:





1. The glasss by the washing machine to clean after drying,the one on the corner of a piece of glass paste interval article,article straighten interval,and edge of the glass to keep a distance of  2.5~3.0mm,

and then from the edge of the glass will be around full article interval,Good sealing tape on interfaces,Pincer-like device reserved 2mm-3mm gap,and about 20mm apart more joint,

insert the sealing tape in space,then joint pressure sealing tape,pinched connectors.warm edge spacer, warm edge truseal spacer, warm edge super spacer, warm edge duralite spacer, warm edge duraseal spacer, warm edge duraseal spacer, truseal warm edge spacer, super warm edge spacer, duralite warm edge spacer, duraseal warm edge spacer, swiggle warm edge spacer, truseal flexible warm edge spacer, super flexible warm edge spacer.

2. Put another piece of glass paste good spacing bar glass above,two pieces of glass must be mutual alignment,up and down to the flat.

3. Will paste together of hollow glass into hot press,hot pressing temperature control between 110-140℃,the outlet temperature control between 50-60 ℃.

4. According to the structure requirement to normal play a two-component silicone sealant,thus insulating glass production.

5. This product seal must be carried out in accordance with the article butyl interval sealing operation schematic drawing process,otherwise may cause the seal leakage.



Introduction:



Anti fungal warm sealing spacer is new product of our company launches,make improvement and innovation in a lot of the original  sealing spacer ,which overcomes the shortcomings of traditional  sealing spacer,retains the original merits.

New warm sealing spacer filled the gap,in the domestic leading position,reached the international level of similar products,compared to the traditional sealing spacer has been greatly improved,

Insulating glass production is revolutionary progress.duralite flexible warm edge spacer, duraseal flexible warme dge spacer, rubber strip spacer, butyl glass gasket for insulating glass, insulating glass sealing spacer, insulating glass sealing spacer, warm edge insulating glass sealing spacer, warm edge hollow glass sleaing spacer, warm edge rubber spacer



Features:



Widely used to manufacturing building doors and windows,train,hollow glass,Bus hollow glass.

1. Sealing spacer surface smooth, no bubbles, bond is strong.warm edge insulating glass sealing spacer, insulating glass warm edge sealing spacer, warm edge spacer equipment, warm edge spacer glass machine, warm edge, warm edge spacer system, warm edge sealing spacer, warm edge insulating glass sealing spacer,Truseal Warm Edge Spacer,warm edge sealing spacer, warm edge insulating glass sealing spacer ,insulating glass sealing spacer,warm edge rubber spacer strip.

2. The operation is simple, the sealing spacer can turn free, eliminating the inserted angle and two sealing problem of the traditional aluminum strip type insulating glass.

3. Good heat insulation performance.

4. Higher water absorbing ability

5. Good sealing, moisture resistance and heat insulation,effectively extending the service life of the insulating glass.



FAQ

Q: Can you make the product according to my design or proto type?



A: Yes. We have an experienced team for working out the most suitable design and production plan for the product that you are going to book with us



Q: Are you a factory or trading company ?



A: We are a factory?



Q: Where is your factory located?



A: Our factory is located in Panjin City, LiaoNing Province, China. All our clients, from home or abroad, are warmly welcome to visit us !



Q: How do you guarantee the quality of the products?



A: Strict product quality, unqualified resolute don't factory. This is the tenet of our factory



Every one of our products have strict testing procedures, must be 100% quality assurance.



Our Services

1. We have professional engineers to solve the problem

2. Any time you can contact our services

3. We can according you needs to design the logo

4. We can according you needs control

5. Prompt reply answer within 24 hours
