Product Details:
Payment & Shipping Terms:
|
| Name: | CNC Automatic Drilling Machine For Cookware Tops Glass / Stove Glass | Model: | Horizontal |
|---|---|---|---|
| Control System: | CNC | Application: | Home Appliance Panel Glass CNC Drilling,Stove Glass CNC Drilling,Car&Truck Side Glass CNC Drilling,Lighting Glass CNC Drilling,Furniture Glass CNC Drilling,TV Monitor Panel Glass CNC Drilling,TV Monitor Backplane Glass CNC Drilling,TV Monitor Base Glass CN |
| High Light: | vertical glass drilling machine,deep hole Drilling Equipment |
||
| Place of Origin: | China |
|---|---|
| Brand Name: | Saint Best |
| Certification: | Valid |
| Model Number: | SBT-A16-1 |
| CNC Glass Drilling Machine: | Automatic CNC Glass Drilling Machine |
| Automatic Glass Drilling Machine: | CNC Automatic Glass Drilling Machine |
| Glass Drilling Machine: | Horizontal Glass Drilling Machine |
| CNC Horizontal Glass Drilling Machine: | Automatic CNC Horizontal Glass Drilling Machine |
| Automatic Horizontal Glass Drilling Machine: | CNC Automatic Horizontal Glass Drilling Machine |
| CNC Glass Driller: | Automatic CNC Glass Driller |
| Minimum Order Quantity: | 1Set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Customized |
| Delivery Time: | 15~30days |
| Payment Terms: | T/T |
| Supply Ability: |
48Sets/Month |
Technical Requirements & Configuration Parameter
Function Technical Parameters
|
Processing effective Range (Drilling hole range) |
X axis |
0—800 |
[mm] |
||
|
Y axis |
0—400 |
[mm] |
|||
|
Drilling hole precision |
X axis |
±0.3 |
[mm] |
||
|
Y axis |
±0.3 |
[mm] |
|||
|
Glass thickness |
6-12 |
[mm] |
|||
|
Drilling Diameter |
φ100 – φ220 |
[mm] |
|||
|
The speed of drilling hole |
φ100 mm (data provided by customer) |
≤ 20 |
[ s ] |
||
|
φ160 mm (data provided by customer) |
≤ 40 |
[ s ] |
|||
|
Qty for setting coordinates |
X axis-10 points Y axis-10 points |
||||
|
Starting point coordinates |
Top left corner |
||||
|
The speed of movement |
X axis |
0 -- 220 |
mm / S |
||
|
Y axis |
0 -- 220 |
mm / S |
|||
|
Ball screw propulsion speed |
Z 1 axis |
0 -- 3 |
mm / S |
||
|
Z 2 axis |
0 -- 3 |
mm / S |
|||
|
Overall Size |
L X W X H 1600 X 2000 X1800 [mm] |
||||
|
The height of the table
|
900 +/- 50 [mm] |
||||
|
Installation condition |
Power |
Voltage |
3 x 380 V / 50 Hz |
||
|
Watt |
4.5 KW |
||||
Application:Home Appliance Panel Glass CNC Drilling,Stove Glass CNC Drilling,Car&Truck Side Glass CNC Drilling,Lighting Glass CNC Drilling,Furniture Glass CNC Drilling,TV Monitor Panel Glass CNC Drilling,TV Monitor Backplane Glass CNC Drilling,TV Monitor Base Glass CNC Drilling
Our CNC Automatic Glass Drilling machine features: High drilling efficiency, accurate positioning and ease of operation.CNC Automatic Glass Drilling Machine for Shower Glass / Shower Door,Shower Glass Industry L Shape CNC Glass Drilling Machine,CNC Glass Drilling Machine For Shower Door
CNC Glass Drilling Machine,Automatic Glass Drilling Machine,Automatic CNC Glass Drilling Machine,CNC Automatic Glass Drilling Machine.
Our main glass drilling machines are applied to following areas:
NO.1: CNC Drilling Machine for Electronic/Household Electrical Appliances Glass
NO.2: CNC Drilling Machine for Furniture Glass
NO.3: CNC Drilling Machine for Shower Room Glass
NO.4: CNC Drilling Machine for Automobile Glass
NO.5: CNC Drilling Machine for Photovoltaic Solar Glass
NO.6: CNC Drilling Machine for Architectural Glass
NO.7: Other Glass Deep-processing Equipment Which Product According to Order.
We sincerely welcome friends from all over the world,home or abroad, to visit our company, negotiate business with us and create a brilliant future together!CNC Appliance Glass Drilling Machine,Automatic CNC Appliance Glass Drilling Machine,CNC Shower Glass Drilling Machine,Automatic CNC Shower Glass Drilling Machine,CNC Furniture Glass Drilling Machine,Automatic CNC Furniture Glass Drilling Machine,CNC Automotive Glass Drilling Machine
Why choose Saint Best products??
1.Saint Best product is widely used in almost all the materials which you can think of.
2.Saint Best machine with high precision and high reputation is the most reliable goods you can choose.
3.Saint Best company has all kinds machines in store, the delivery time is much shorter than other companies.
4.Guarantee the complete machine for 12 months, except the consumable parts.
5.Saint Best company has international tech service office and provides 24 hours online service and tech support for customers.
Services
The engineer is available to travel aboard, help the installation, maintenance and training staff.
By offering this support, we make sure the customer start the business smoothly, to realize win-win cooperation.
We always looking for long term cooperation, not one time deal.
Packing & Shipping
Demac produce high quality machines, also pay attention to package. Wooden case, pallet, and special package to make sure customer will receive the machines they ordered intact.
