CNC Four Head Aluminium Window Corner Crimping Machine for Window and Door, Aluminium Window Corner Crimping Machine

China CNC Four Head Aluminium Window Corner Crimping Machine for Window and Door, Aluminium Window Corner Crimping Machine supplier
CNC Four Head Aluminium Window Corner Crimping Machine for Window and Door, Aluminium Window Corner Crimping Machine supplier CNC Four Head Aluminium Window Corner Crimping Machine for Window and Door, Aluminium Window Corner Crimping Machine supplier CNC Four Head Aluminium Window Corner Crimping Machine for Window and Door, Aluminium Window Corner Crimping Machine supplier CNC Four Head Aluminium Window Corner Crimping Machine for Window and Door, Aluminium Window Corner Crimping Machine supplier

Large Image :  CNC Four Head Aluminium Window Corner Crimping Machine for Window and Door, Aluminium Window Corner Crimping Machine

Product Details:

Place of Origin: CHINA
Brand Name: SAINT BEST
Certification: CE/ISO9001
Model Number: CLM4S-100x1800x3000

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set Aluminum Window Four Head Corner Crimping machine
Price: CNC Vertical Four-Point Corner Crimping Machine
Packaging Details: Wooden Case or customized
Delivery Time: 15~30days
Payment Terms: T/T, Western Union, MoneyGram,Paypal
Supply Ability: 48Sets/Month CNC Aluminum Window Corner Crimping Machine
Contact Now
Detailed Product Description
CNC Aluminum Window Corner Crimping Machine: CNC Aluminum Window Four Head Corner Crimping Machine Aluminium Four Head Window Door Processing Crimping Machine: CNC Aluminium Four Head Window Door Processing Crimping Machine
Aluminum Window Machine Four Head Corner Crimping Machine: Aluminum Window Machine CNC Four Head Corner Crimping Machine Max. Frame Size: 1800mm*3000mm
Min Frame Size: 480mm*480mm Height: 93mm
Aluminum Window Corner Crimping Machine: Aluminum Window Four Head Corner Crimping Machine
High Light:

aluminium fabrication machinery

,

aluminium window machine



CNC Four Head Aluminium Window Corner Crimping Machine for Window and Door

Quick Details

  • Brand Name: SAINT BEST
  • Model Number: CLM4S-100*1800*3000
  • Product name: CNC Four Head Aluminium Window Corner Crimping Machine / Four Head Corner Combining Machine for Aluminum Window and Door
  • Voltage: 380/220V
  • Rating power: 7.5kw
  • Rating oil pressure: 15MPa
  • Air consumption pressure: 0.5-0.8MPa
  • Air consumption: 0.45 L once
  • Capability of oil box: 60L
  • Corner crimping cylinder journey: 0-50mm
  • Max frame dimension: 1800*3000mm
  • Keyword: window door processing crimping machine

Packaging & Delivery

Packaging Details: Aluminium Four Head Window Door Processing Crimping Machine
1.Simple stretch film packaging;
2.Professional export wooden packing.
Delivery Detail: Shipped in 20 days after payment



Equipment Description

Main Feature:

1.Use for corner punching combination of aluminum window&door,four corners connecting at one time is available.

2.Clamping device can auto move forward/backward,making the operation convenient.

3.The frame is specially jointed by steel with high quality and special process.

4.The CNC system imported from MTSUBISHI JANPAN,with high quality ensures the speed and accuracy.

5.The moment control function of the service system can auto-press the four corners ensuring the processing effect.

6.The corner-crimping blade can be adjusted according to the requirement of different profile.

7.One time corner crimping can control the seam and plane,make the quality foresight.CNC Four Head Aluminium Window Corner Crimping Machine,Four Head Corner Combining Machine for Aluminum Window and Door.

8.The control system and servo system make the connect no seam and improve the control accuracy.



CNC Four Head Aluminium Window Corner Crimping Machine for Window and Door, Aluminium Window Corner Crimping MachineCNC Four Head Aluminium Window Corner Crimping Machine for Window and Door, Aluminium Window Corner Crimping MachineCNC Four Head Aluminium Window Corner Crimping Machine for Window and Door, Aluminium Window Corner Crimping Machine

Main Technical Parameter:

Model CLM4S-100*1800*3000
Power Supply 380V 50Hz
Rating Power 7.5Kw
Rating oil pressure 15MPa
Air Pressure 0.5~0.8MPa
Air consumption 0.45Lonce
Capability of oil box 60L
Corner crimping casing movement distance 0-50mm
Max. frame dimension 1800mm*3000mm
Min. frame dimension 480mm*480mm
Profile width 93mm
Tolerance of diagonal ≤1mm
Tolerance of connection seam ≤0.15mm
Overall Dimension 4700*2200*2500mm
Weight About 2500Kg
Related Products >>
CNC Four Head Aluminium Window Corner Crimping Machine for Window and Door, Aluminium Window Corner Crimping Machine






Our Service
CNC Four Head Aluminium Window Corner Crimping Machine for Window and Door, Aluminium Window Corner Crimping Machine

Pre-sale service

●Free contact for the most suitable machine
●Free professional design for each customer especially.

After sale service

●24 hours technical support by phone, email or skype
●1years warranty period
●Our senior engineer is available to travel aboard, help the installation, maintenance and training staff.

Payment
●T/T, 30% deposit by T/T,70% payment before shipment.
●Western Union or Paypal.

Our Factory
Our company is a manufacturer of window machine, insulating glass processing machine and curtain wall machine with well-equipped testing equipment and strong technical force. With a wide range, good quality, reasonable prices and stylish designs, our products are extensively used in building trade and other industries. Hope we can cooperate with you.


Saint Best Group Factory Details:

+ Our factory has two large fabricating factories;

+ Our factory has our own office building and staff apartment;

+ Our factory has 25 fabricating workers which have more than 10 years window door and insulating glass fabricating experience;

+ Any more details, welcome to contact us our customer service department at any time on line.

CNC Four Head Aluminium Window Corner Crimping Machine for Window and Door, Aluminium Window Corner Crimping Machine
FAQ

1. When can we arrange shippment?
We usually arrange shippment within 15 days after getting deopsit,
but customized machines should be more than 25 days.

2.What you can do if my machines have problems?
1) We can send you free components to you if your machines are in guarantee time.
2) We can send our engineers to repair your machines


3.Do you provide equipment operation training?
Yes. We can send professional engineers to the working site for equipment installation, adjustment, and operation training. All of our engineers have passport.



4 How is Aluminium Four Head Window Door Processing Crimping Machine guarantee?

4.1. Aluminium Four Head Window Door Processing Crimping Machine warrenty period is 14 months after BL time;

4.2.12 hours technical support feedback;

4.3. Own window factory supply window fabrication support;

4.4. Own machining factory, which can control the spare parts quality at high quality;

4.5. Own accessories warehouse and user can enjoy the agent price.



5 How is our package?

 Wooden Pallet/ Wooden Case. In order to ensure high quality products precision, the perfect package is necessary.



6 Why is price higher than other supplier?

6.1. We have our own machining factory and the high quality technical quality is our aim;

6.2. All the electric parts and pneumatic parts are high quality. Most of them are imported from european and american market;

6.3. Most of fabricating worker has more than 10 years working time. Their fabricating work is professional and salary is higher;

6.4. Our warrenty period is 14 months after BL time. It can support the new comer client going well in the beginning time.
